- Description: Inlet, panel mounting, 6h, 125A, IP67, unified flange, straight, 3P+N+E
- Product ID: 2CMA167204R1000
- Extended Product Type: 2CMA167204R1000
- Product Net Weight: 1 kg
- Product Net Width: 130 mm
- Product Net Height: 145 mm
- Product Net Depth: 145 mm
- Product Main Type: TBU
- Product Name: Industrial Inlet for Panel Mounting
- Degree of Protection: IP67
- Standards: IEC 60309-1,-2
- Number of Poles: 4
- Rated Current (I<sub>n</sub>): 125 A
- Function: Inlet, panel mounting, unified flange, straight
- Color: Red
- Suitable For: Inlets for Panel Mounting
- Product Net Length: 127 mm
- Rated Voltage (U<sub>r</sub>): 346 415 V
- Country of Origin: Czech Republic (CZ)
- Frequency (<i>f</i>): 50 Hz
- Mounting Type: unified flange, straight
- Enclosure Material: Thermoplastic polyester (PBT)
- Environmental Information: 2CMC700001D0002
- Protection Type: Watertight
- Cable Cross-Section: 16 70 mm
- EAN: 7392696672047
- Minimum Order Quantity: 1 piece
- Package Level 1 Width: 131 mm
- Package Level 1 Length: 162 mm
- Package Level 1 Height: 127 mm
- Package Level 1 Gross Weight: 1.1 kg
- Package Level 1 EAN: 7392696672047
- Package Level 1 Units: 1 piece
- RoHS Status: Planned to follow EU Directive 2002/95/EC August 18, 2005 and amendment after 2006-03-01
- Declaration of Conformity - CE: 2CMC700005D0001
- RoHS Information: 2CMC700057D0001
- Additional Information: IP69
- IIT Publishing Status: Level 0 - Information enabled
- Invoice Description: Ind. P&S#4125BU6W
- Object Classification Code: 2CMT005069
- RoHS Date: L23
- Suitable for Product Class: Industrial Plugs and Sockets
- E-nummer: 2417431
- UNSPSC: 39120000
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on 4125BU6W . Santa Clara Systems carries 36,687 items from ABB.
- Straight
- 3-Poles+neutral+earth
- Frequency 50-60 Hz
- Color Code Red
- Inlet
- Panel Mounting
- Earthing Sleeve Position 6h
- Rated Current 125a
- Ip67 Watertight
- Unified Flange
