- Description: High Speed Counter/Encoder Module | Compact I/O
- Wire size: 0.32... 2.1 mm (22... 14 AWG) solid copper wire or 0.32... 1.3 mm (22... 16 AWG) stranded copper wire rated at 90*C (194*F) insulation max
- Dimensions (H x W X D), approx: 118 x 35 x 87 mm (4.65 x 1.38 x 3.43 in.) height including mounting tabs is 138 mm (5.43 in)
- Shipping weight (with carton), approx: 309 g (0.681 lb)
- Bus current draw, max: 425 mA at 5V DC, 0 mA at 24V DC
- Heat dissipation: 6.21 W the watts per point, plus the minumum Watts, with all points energized
- Isolation voltage: 75V (continuous), reinforced insulation type, channel-to-system and channel-to-channel. Type tested at 1200V AC for 2 s
- All supply power and/or current ratings - Input: 30V DC, 40*C (104*F)
- All supply power and/or current ratings - Output: 1 A per channel, 4 A per module, 30V DC, 40*C (104*F)
- Power supply distance rating: Module cannot be more than four modules away from a system power supply
- Recommended cable: Individually shielded, twisted-pair cable (or the type recommended ny the encoder or sensor manufacturer)
- Wiring category: 2 - on signal ports
