- Description: HK-20 Auxiliary Contact
- Product ID: 1SAM101901R0002
- Extended Product Type: 1SAM101901R0002
- Product Net Weight: 0.03 kg
- Product Net Width: 9 mm
- Product Net Height: 86 mm
- Product Net Depth: 72 mm
- Product Name: Auxiliary Contact
- Degree of Protection: IP20
- Ambient Air Temperature: Operation -25 …. +50 °C Storage -50 …+80 °C
- Standards: IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 60947-5-1 UL 60947-1 UL 60947-4-1
- Rated Impulse Withstand Voltage (U<sub>imp</sub>): Auxiliary Circuit 6 kV
- Rated Insulation Voltage (U<sub>i</sub>): 690 V
- Rated Frequency (f): Auxiliary Circuit DC Auxiliary Circuit 50 Hz Auxiliary Circuit 60 Hz
- Suitable For: MS325 MO325
- eClass: 7.0 27379201
- Tightening Torque: Auxiliary Circuit 0.8 … 1.0 N·m
- Number of Auxiliary Contacts NO: 2
- Number of Auxiliary Contacts NC: 0
- GOST Certificate: 1SAA918000-2703
- Tightening Torque UL/CSA: Auxiliary Circuit 7 in·lb
- Connecting Capacity Auxiliary Circuit: Rigid 1/2x 1.0 … 2.5 mm² Flexible with Ferrule 1/2x 0.75 ... 1.5 mm² Flexible 1/2x 0.75 … 2.5 mm² Flexible with Insulated Ferrule 1x 0.75 ... 2.5 mm² Flexible with Insulated Ferrule 2x 0.75 mm²
- Country of Origin: Switzerland (CH)
- Wire Stripping Length: Auxiliary Circuit 8 mm
- Lead Time: 60 day(s)
- EAN: 4013614139642
- Made To Order: No
- Product Sales Status: Active
- Quote Only: No
- You searched for alternate part: 1SAM101901R0002
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85369085
- Package Level 1 Length: 79 mm
- Package Level 1 Height: 105 mm
- Package Level 1 Gross Weight: 0.365 kg
- Package Level 1 EAN: 4013614442322
- Package Level 1 Units: 10 piece
- Package Level 1 Width: 210 mm
- Rated Operational Current AC-15 (I<sub>e</sub>): (24 V) 3 A (120 V) 3 A (240 V) 2 A (380 / 400 V) 0.5 A
- Rated Operational Current DC-13 (I<sub>e</sub>): (24 V) 2.5 A (125 V) 0.55 A (250 V) 0,27 A
- Recommended Screw Driver: Pozidriv 2
- Suitable for Product Class: Manual Motor Starter
- Rated Operational Voltage: 400 V AC 250 V DC
- RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
- Connecting Capacity Auxiliary Circuit UL/CSA: Stranded 1/2x 14 ... 18 AWG Flexible 1/2x 14 ... 8 AWG
- Contact Rating UL/CSA: B300 Q300
- Instructions and Manuals: 1SAM107008P0002
- CCC Certificate: 1SAA918001-3801
- cUL Certificate: 1SAA918002-1701
- Data Sheet, Technical Information: 1SBC100173C0201
- Declaration of Conformity - CE: 1SAD938504-0021 1SAD938506-0037 1SAD938513-0003
- RoHS Information: 1SAA918001-4402
- UL Certificate: 1SAA918002-1601
- E-nummer: 3111372
- ETIM 4: EC002498 - Accessories for low-voltage switch technology
- ETIM 5: EC002498 - Accessories for low-voltage switch technology
- ETIM 6: EC002498 - Accessories for low-voltage switch technology
- UNSPSC: 39121500
- Object Classification Code: Q
