Description: 32-Point Controller | MicroLogix 1400
Enclosure Type: None - Open-Style
Product Type: Programmable Controller
Weight: 0.9 kg (2.0 lbs)
Number of I/O: 24 inputs (20 digital and 4 analog) and 14 outputs (12 digital and 2 analog)
Power Supply Voltage: 24V DC Class 2 SELV
Power Consumption: 50W | 7.5W (with no 1762 expansion I/O)
Output Circuit Type: Relay/FET

Relay/FET Output - Max. Controlled Load: 1080 VA
Relay/FET Output - Max. Continuous Current per Channel: 2.5 A per Channel
Dimensions HxWxD: 90 x 180 x 87 mm (3.5 x 7.087 x 3.43 in.)
Power Supply Inrush Current: 24V DC: 15 A for 20 ms
Input Circuit Type: Digital: 24V DC | sink/source (standard and high-speed) | Analog: 0...10V DC
Relay Output - Load Current: 10 mA (minimum)
Relay Output - Turn on/off Time: 10 ms (maximum) {Scan time dependent}
