- Description: BJMI8-2 POLES Jumper Bars
- Product ID: 1SNA176669R1600
- Extended Product Type: 1SNA176669R1600
- Product Net Weight: 4.5 g
- Degree of Protection: acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20
- Rated Current (I<sub>n</sub>): Main Circuit 41 A
- Function: Jumper Bars
- Suitable For: C6/8 D2.5/8.ADO D2.5/8.ADO.NF D4/8.ADO D4/8.ADO.NF D6/8.ADO D6/8.ADO.NC D6/8.ADO.RS D6/8.D2.ADO M4/8.D2.SB M4/8.D2.SF M4/8.D2.SF.NC M6/8 M6/8.D M6/8.D2.NC M6/8.NC M6/8.RS
- Mounting on DIN Rail: G32 (32 x 15 mm Mounting Rail) acc. to IEC 60715 TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
- Spacing: 8 mm
- EAN: 3472591766691
- Minimum Order Quantity: 10 piece
- Customs Tariff Number: 85369010
- Instructions and Manuals: 1SNC160001C0207-CH-J Accessories
- Data Sheet, Technical Information: 1SNC160001C0207-CH-J Accessories
- Declaration of Conformity - CE: 1SND225001C1009
- RoHS Information: 1SND230492F0201
- ETIM 4: EC000489 - Cross-connector for terminal block
- ETIM 5: EC000489 - Cross-connector for terminal block
- ETIM 6: EC000489 - Cross-connector for terminal block
- Object Classification Code: X
- Package Level 1 Width: 155 mm
- Package Level 1 Length: 200 mm
- Package Level 1 Height: 5 mm
- Package Level 1 Gross Weight: 0.045 kg
- Package Level 1 EAN: 3472591766691
- Package Level 2 Units: 800 piece
- Package Level 3 Units: 144000 piece
- Product Packing Type: Bag
- Package Level 1 Units: 10 piece
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on BJMI8-2 . Santa Clara Systems carries 36,687 items from ABB.
- - Allows Connection Between Consecutive Blocks Only.
- - Ip20 Assembled Screw Jumper Bars
- - Fractionnable Model With Captive Screws And Spacers
Alternates
- 1SNA176669R1600
- BJMI8-2P-IP20
- BJMI8 2P IP20
- BJMI82PIP20
