CR-U012DC2L

ABB - CR-U012DC2L Pluggable interface relay 2c/o, A1-A2=12VDC, 250V/10A, LED

Current response time:

8 Minutes 40 Seconds

Description: CR-U012DC2L Pluggable interface relay 2c/o, A1-A2=12VDC, 250V/10A, LED
Product ID: 1SVR405621R4100
Extended Product Type: 1SVR405621R4100
Product Net Weight: 0.083 kg
Product Net Width: 35 mm
Product Net Height: 54.4 mm
Product Net Depth: 35 mm
Function: Pluggable universal interface relay CR-U
eClass: 7.0 27371601
GOST Certificate: GOST_POCC_DE.AB76.D02256
Rated Control Supply Voltage (U<sub>s</sub>): 12 V DC
Sub-Function: Relay with built in LED
Output: 2 c/o (SPDT) contacts
EAN: 4013614498442
Minimum Order Quantity: 10 piece
Customs Tariff Number: 85364900
Package Level 1 Width: 182 mm
Package Level 1 Height: 76 mm
Package Level 1 Length: 77 mm
Package Level 1 Gross Weight: 0.87 kg

Package Level 1 EAN: 4013614374081
Package Level 1 Units: 10 piece
Output Signal: 250 V / 10 A
RoHS Status: Following EU Directive 2011/65/EC
Instructions and Manuals: 1SVC405600M9000
CCC Certificate: CCC_2012010303554029
CSA Certificate: CSA_1587291
Data Sheet, Technical Information: 2CDC117003D0205
Declaration of Conformity - CE: 1SVD982021-0000
EAC Certificate: EAC_RU_C-PL.ME77.B.01873
LR Certificate: LR_05_20002_E3
RMRS Certificate: RMRS_12.04008.250
RoHS Information: 1SAA981040-4404
UR Certificate: UR_E244330
VDE Certificate: VDE_40019116
ETIM 4: EC001437 - Switching relay
ETIM 5: EC001437 - Switching relay
ETIM 6: EC001437 - Switching relay
UNSPSC: 39121500
Object Classification Code: K

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on CR-U012DC2L . Santa Clara Systems carries 37,000 items from ABB.

Holder And Marker Are Available As Accessories.

The Cr-U012dc2l Pluggable Interface Relay Is From The Cr-U (Universal) Relay Range. This Relay Operates With A 12 V Dc Rated Control Supply Voltage And Has 2 C/o (Spdt) Output Contacts Rated At 250 V / 10 A. The Relay Has An Integrated Blue Test Button For Manual Actuation And Locking Of The Output Contacts And An Integrated Led. Standard Sockets
