- Description: D1.5/6.ADO IDC Terminal Blocks - Feed-through ADO - ADO - Orange
- Product ID: 1SNA199052R2700
- Extended Product Type: 1SNA199052R2700
- Product Net Weight: 6 g
- Product Net Width: 6 mm
- Product Net Height: 45.5 mm
- Product Net Depth: 41 mm
- Degree of Protection: acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20
- Ambient Air Temperature: Operation -55 ... +110 °C Storage -55 ... +110 °C
- Rated Impulse Withstand Voltage (U<sub>imp</sub>): 8000 V
- Rated Current (I<sub>n</sub>): Main Circuit 17.5 A
- Function: Feed-through
- Color: Orange
- Mounting on DIN Rail: TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
- Maximum Operating Voltage UL/CSA: Main Circuit 600 V
- Rated Voltage (U<sub>r</sub>): 1000 V
- Connecting Capacity UL/CSA: Stranded 16 AWG
- Spacing: 6 mm
- Dielectric Test Voltage: 3500 V
- Insulation Material: Polyamide
- Connection Type: ADO System
- Rated Cross-Section: 1.5 mm²
- Number of Levels: 1
- EAN: 3472591990522
- Minimum Order Quantity: 50 piece
- Customs Tariff Number: 85369010
- Rated Short-time Withstand Current (I<sub>cw</sub>): for 1 s 180 A
- Pollution Degree: 3
- Flammability According to UL94: V0
- RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
- Instructions and Manuals: 1SNC160020C0201
- BV Certificate: 1SND163013A0200
- CB Certificate: 1SND163011A0200
- cUL Certificate: 1SND163001A0202
- Data Sheet, Technical Information: 1SNC160020C0201
- Declaration of Conformity - CE: 1SND225025U1000
- EAC Certificate: 1SND162001A1100
- RoHS Information: 1SND230472F0201
- ETIM 4: EC000897 - Feed-through terminal block
- ETIM 5: EC000897 - Feed-through terminal block
- ETIM 6: EC000897 - Feed-through terminal block
- Object Classification Code: X
- Package Level 1 Width: 61 mm
- Package Level 1 Length: 220 mm
- Package Level 1 Height: 47 mm
- Package Level 1 Gross Weight: 0.3 kg
- Package Level 1 EAN: 3472591990522
- Package Level 2 Units: 1000 piece
- Package Level 2 Width: 300 mm
- Package Level 2 Length: 500 mm
- Package Level 2 Height: 150 mm
- Package Level 2 Gross Weight: 6.35 kg
- Package Level 3 Units: 48000 piece
- Product Packing Type: Box
- Package Level 1 Units: 50 piece
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on D1.5-6.ADO-1SNA199052R2700 . Santa Clara Systems carries 37,000 items from ABB.
- Corrosion Etc.)
- - Up To 2 Wires Per Connection.
- - With The Abb Ado System®
- Experience The Fastest And Most Reliable Connection On The Market
- - Designed For Control Applications Exposed To Severe Constrains (Vibrations
- Shocks
