- Description: E256-24 Latching relay
- Product ID: 2CSM414000R0201
- Extended Product Type: 2CSM414000R0201
- Product Net Weight: 0.130 kg
- Product Net Width: 0.018 m
- Product Net Height: 0.085 m
- Product Net Depth: 0.085 m
- Power Loss: at Rated Operating Conditions per Pole 0 W
- Number of Main Contacts NO: 1
- Number of Main Contacts NC: 1
- Rated Control Supply Voltage (U<sub>s</sub>): 24 V AC
- Current Rating: 16 A
- EAN: 8012542531807
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85364190
- Package Level 1 Width: 0.075 m
- Package Level 1 Height: 0.09 m
- Package Level 1 Length: 0.215 m
- Package Level 1 Gross Weight: 1.46 kg
- Package Level 1 EAN: 8012542531814
- Package Level 1 Units: 12 piece
- RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
- Instructions and Manuals: On the product's body
- Data Sheet, Technical Information: 2CSC400002D0209
- Declaration of Conformity - CE: ITSCE036E25x
- RoHS Information: 2CSC441003K0201
- E-nummer: 4026453
- ETIM 4: EC000188 - Latching relay
- ETIM 5: EC000188 - Latching relay
- Object Classification Code: K
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on E256-24 . Santa Clara Systems carries 36,687 items from ABB.
- E250 Allows Contact Switching For Each Impulse Sent To Coil
- E250 Allows Contact Switching For Each Impulse Sent To Coil
- Using Normally Open Pushbuttons. Ideal For Lamp Remote Controlling From Different Positions. They Also Allow Manual Operations On The Product.
