• ABB HK1-20L HK1-20L Auxiliary Contact Product Image
  • Abb HK1-20L Barcode

HK1-20L

Product Summary:

  • Product ID: 1SAM201902R1004
  • Extended Product Type: 1SAM201902R1004
  • Product Net Weight: 0.035 kg
  • Product Net Width: 9 mm
  • Product Net Height: 90 mm
Let Us Find It

Current response time:

4 Minutes 11 Seconds
  • Description: HK1-20L Auxiliary Contact
  • Product ID: 1SAM201902R1004
  • Extended Product Type: 1SAM201902R1004
  • Product Net Weight: 0.035 kg
  • Product Net Width: 9 mm
  • Product Net Height: 90 mm
  • Product Net Depth: 78.5 mm
  • Product Name: Auxiliary Contact
  • Standards: IEC/EN 60947-1 IEC/EN 60947-4-1 IEC/EN 60947-5-1 UL 60947-1 UL 60947-4-1
  • Rated Impulse Withstand Voltage (Uimp): Auxiliary Circuit 6 kV
  • Rated Insulation Voltage (Ui): 690 V
  • Suitable For: MS116 MS132
  • eClass: 7.0 27379201
  • Tightening Torque: Auxiliary Circuit 0.8 1.2 N·m
  • Number of Auxiliary Contacts NO: 2
  • Number of Auxiliary Contacts NC: 0
  • GOST Certificate: 1SAA937000-2703
  • Maximum Operating Voltage UL/CSA: Main Circuit 600 V
  • Tightening Torque UL/CSA: Auxiliary Circuit 7 in·lb
  • Connecting Capacity Auxiliary Circuit: Rigid 1/2x 1 ... 1.5 mm Flexible with Ferrule 1/2x 0.75 ... 1.5 mm Flexible with Insulated Ferrule 1/2x 0.75 ... 1.5 mm Flexible 1/2x 0.75 ... 1.5 mm
  • Wire Stripping Length: Auxiliary Circuit 8 mm
  • GL Certificate: 1SAA963001-0401 1SAA963000-0402
  • EAN: 4013614365881
  • Minimum Order Quantity: 2 piece
  • Customs Tariff Number: 85365080
  • Package Level 1 Length: 80 mm
  • Package Level 1 Height: 93 mm
  • Package Level 1 Gross Weight: 0.08 kg
  • Package Level 1 EAN: 4013614481482
  • Package Level 1 Units: 2 piece
  • Package Level 1 Width: 25 mm
  • Rated Operational Current AC-15 (Ie): (24 V) 6 A (240 V) 4 A (380 / 400 V) 3 A (690 V) 1 A
  • Rated Operational Current DC-13 (Ie): (24 V) 2 A (125 V) 0.55 A (250 V) 0,27 A (440 V) 0.15 A (600 V) 0.15 A
  • Recommended Screw Driver: Pozidriv 2 M3
  • Suitable for Product Class: Manual Motor Starter
  • Rated Operational Voltage: 690 V AC 600 V DC
  • RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
  • Connecting Capacity Auxiliary Circuit UL/CSA: Stranded 1/2x 16 ... 14 AWG Flexible 1/2x 16 ... 14 AWG
  • Instructions and Manuals: 2CDC131011M6802 2CDC131034M6801 2CDC131022M6802
  • ABS Certificate: 1SAA963001-0101
  • BV Certificate: 1SAA963000-0202
  • CB Certificate: 1SAA963001-2002
  • CCC Certificate: 1SAA963003-3802
  • cUL Certificate: cUL_E137861
  • Data Sheet, Technical Information: 1SBC100192C02--
  • Declaration of Conformity - CE: 1SAD938501-0191 1SAD938516-0060 1SAD938502-0188 1SAD938504-0183 1SAD938502-0190 1SAD938510-0125
  • DNV Certificate: 1SAA963001-0303
  • LR Certificate: 1SAA963001-0502 1SAA963001-0501 1SAA963000-0505 1SAA918001-0501
  • RINA Certificate: 1SAA963000-0802
  • RoHS Information: 1SAA963001-4407
  • UL Certificate: UL_E137861
  • ETIM 4: EC002498 - Accessories for low-voltage switch technology
  • ETIM 5: EC002498 - Accessories for low-voltage switch technology
  • ETIM 6: EC002498 - Accessories for low-voltage switch technology
  • UNSPSC: 39121500
