S2C-UA-12DC

ABB - S2C-UA 12 DC - Undervoltage release

Current response time:

By 5AM PT on Tuesday

Emergency?

Description: S2C-UA 12 DC - Undervoltage release
Product ID: 2CSS200911R0001
Extended Product Type: 2CSS200911R0001
Product Net Weight: 0.090 kg
Product Net Width: 0.018 m
Product Net Height: 0.085 m
Product Net Depth: 0.074 m
Product Main Type: S2C-UA
Product Name: Undervoltage release
Suitable For: S200, SN201, F200, DS201, DS202C, DS200
EAN: 8012542839705
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85389099
Package Level 1 Units: 1 piece

Package Level 1 Width: 0.125 m
Package Level 1 Height: 0.035 m
Package Level 1 Length: 0.11 m
Package Level 1 Gross Weight: 0.1 kg
Package Level 1 EAN: 8012542839705
RoHS Status: Planned to follow EU Directive 2002/95/EC August 18, 2005 and amendment after 2007 Q4
Suitable for Product Class: Miniature Circuit Breakers MCBs Residual Current Devices RCDs Residual Current Breakers with Overload Protection RCBo
Data Sheet, Technical Information: 2CSC400002D0209
Declaration of Conformity - CE: ITSCE0161
RoHS Information: 2CSC490002K0201
ETIM 4: EC000042 - Miniature circuit breaker (MCB)
ETIM 5: EC000042 - Miniature circuit breaker (MCB)
Object Classification Code: Q

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on S2C-UA-12DC . Santa Clara Systems carries 37,000 items from ABB.

Ds200 Series. It Can Be Used With Mcbs Sn201 Series By Means Of Sn201-Ih Interface Module. Rated Voltage: 12v D.c.

The S2c-Ua 12 Dc Undervoltage Release Has The Function To Protect The Load In Case Of A Voltage Drop Included Between 70% And 35% Of Its Rated Value. Positive Safety (Device Tripping When The Voltage Is Disconnected) Emergency Stop By Means Of A Button. Suitable For Mcbs S200 Series
Rccbs F200 Series And Rcbos Ds201
Ds202c
