1794-IB16

Product Summary:

  • Number of inputs: 16, current, sinking
  • On-state voltage, min: 10V DC
  • On-state voltage, nom: 24V DC
  • On-state voltage, max: 31.2V DC
  • On-state current, min: 2.0 mA
Get a Quote

Current response time:

By 5AM PT on Monday
  • Description: Input Module | FlexLogix
  • Power dissipation, max: 6.1 W @ 31.2V DC
  • Thermal dissipation, max: 20.8 BTU/hr @ 31.2V DC
  • Off-state voltage, max: 5.0V DC
  • Off-state current, max: 1.5 mA
  • FlexBus current: 30 mA @ 5V DC
  • Dimensions, approx. (H x W x D): 94 x 94 x 69 mm (3.7 x 3.7 x 2.7 in.)
  • Number of inputs: 16, current, sinking
  • On-state voltage, min: 10V DC
  • On-state voltage, nom: 24V DC
  • On-state voltage, max: 31.2V DC
  • On-state current, min: 2.0 mA
  • On-state current, nom: 8.0 mA
  • On-state current, max: 12.0 mA
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on 1794-IB16 . Santa Clara Systems carries 47,270 items from Allen Bradley.
