836T-D462JX9

Allen Bradley - Pressure Difference Control

Current response time:

By 5AM PT on Monday

Emergency?

* Santa Clara Systems is not a Rockwell Automation Authorized Distributor .

Description: Pressure Difference Control
Operator Type: With Type 316 Stainless Steel BellowsType 316 stainless steel bellows are available for more corrosive gasses.
Enclosure Type: Enclosure Type 1, 4 and 13 Industrial use.
Custom Trip or Reset Setting: Default Factory SettingStandard pressure controls shipped from the factory are set at the maximum operating range and minimum differential. These settings vary for each pressure switch family depending on the combination of Style, Operator Type, and Pressure Specification configuration options.
Contact Block Type: S.P.D.T. , 2 - circuit contact block
Maximum Line Pressure: 175 psi

Style of Device: D - Style Pressure Difference ControlIndependently adjustable system difference range and differential, Two bellows operation, one bellows connected to each system.
Adjustable Pressure Selection (Operating Range): 25 psi
Adjustable Differential (Approximate Mid-Range Values): 4 psi
MinPressure: 0 psi
Ordering Modifications: X9, Neon Pilot Light 120V AC

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on 836T-D462JX9 . Santa Clara Systems carries 55,605 items from Allen Bradley.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
