MPL-B310P-MJ74AA

Allen Bradley - Servo Motor

Current response time:

By 5AM PT on Tuesday

Emergency?

* Santa Clara Systems is not a Rockwell Automation Authorized Distributor .

Description: Servo Motor
Voltage: 460 V
Enclosure: Keyed Shaft ExtensionIP50 Housing, IP66 with optional shaft seal installed.
Enclosure: Yes - Shaft Key / No - Shaft Seal
Frame Size: 3 = 100 mm (3.94 in.)
Frame Size: 3 = 100 mm
Voltage Class: 400 V
Product Type: Bulletin MPL - Low-Inertia Brushless Servo Motors Product
Feedback: Multi-turn High-resolution Encoder (absolute feedback)
Feedback: Multi-Turn High-Resolution Encoder
Mounting: IEC Metric, Free Mounting Holes (Type FF)

Connectors: SpeedTEC DIN Connector, Right Angle, 180° Rotatable (Quick Connect)
Brake Option: 24 V DC Brake
RPM: 5000 RPM
Brake: 24V DC Brake
Magnet Stack Length: 10 = 25.4 mm (1.0 in.)
Product Series: MP = Premium Permanent Magnet Rotary Servo Motor
Product Series Type: Low Inertia
Magnetic Stack Length: 25.4 mm (1.0 in.)
Rated Speed: 5000 rpm
Connector: Circular DIN, Right Angle, 180° Rotatable

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on MPL-B310P-MJ74AA . Santa Clara Systems carries 55,492 items from Allen Bradley.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
