E51ALP2

Cutler-Hammer - Photoelectric Sensor Dark Sense | Eaton

Current response time:

By 5AM PT on Thursday

Emergency?

Description: Photoelectric Sensor Dark Sense | Eaton
Input Voltage: 120 Vac
Contact Configuration: L1 Switched, N.O. and N.C.
Operating Mode: Thru-Beam
Operating Temperature: -13° to 158°F (-25° to 70°C)
Switch Type: Photoelectric
Maximum Ac Current: 1.0A
Maximum Dc Current: 500 mA
Connection: Screw terminals
Enclosure Material: Receptacle and body: Die cast Zinc, head: plastic
Sensor Type: Through Beam

Contact Rating: 1.0A Solid State Output
Environmental Rating: NEMA 3,3S,4,4X,6,6P,12,13, IP67
Protection: Latching short circuit
Led Indicators: Red output status for both outputs
Product Length/Depth: 1.54 IN
Product Height: 4.89 IN
Product Width: 1.82 IN
Product Weight: .975 LB
Compliances: CE Marked
Certifications: CSA Certified

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on E51ALP2 . Santa Clara Systems carries 16,336 items from Cutler-Hammer.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
