• Efector KI0205 Capacitive Sensor | KIE2015-FBOA/NI RT Product Image
  • Efector KI0205 Capacitive Sensor | KIE2015-FBOA/NI RT Product Image
  • Efector KI0205 Capacitive Sensor | KIE2015-FBOA/NI RT Product Image
  • Efector KI0205 Capacitive Sensor | KIE2015-FBOA/NI RT Product Image
  • Efector KI0205 Barcode

KI0205

Product Summary:

  • Electrical Design: AC/DC
  • Output Function: Normally Open / Closed Programmable
  • Operating Voltage: 20-250VAC/DC
  • Sensing Range: 15mm; Adjustable 3-15mm
  • Mounting: non-flush mountable
Get a Quote

Current response time:

By 5AM PT on Tuesday
  • Description: Capacitive Sensor | KIE2015-FBOA/NI RT
  • Electrical Design: AC/DC
  • Output Function: Normally Open / Closed Programmable
  • Operating Voltage: 20-250VAC/DC
  • Sensing Range: 15mm; Adjustable 3-15mm
  • Mounting: non-flush mountable
  • Material: PBT; end cap: PC
  • Reverse Polarity Protection: No
  • Ambient Temprature: -25 to 70 (C)
  • Short-Circuit Proof: No
  • Alternate Manufacturer Name: IFM
  • Housing: Threaded type
  • Dimensions [mm]: M30 x 1.5 / L = 125
  • Protection class: II
  • Max. voltage drop switching output DC [V]: 8
  • Max. voltage drop switching output AC [V]: 10
  • Minimum load current [mA]: 5
  • Max. leakage current [mA]: 2.5 (250 V AC) / 1.7 (110 V AC) / 1.5 (24 V DC)
  • Permanent current rating of switching output AC [mA]: 200; (for UL application: 250 / 100 DC)
  • Permanent current rating of switching output DC [mA]: 200; (for UL application: 250 AC / 100 DC)
  • Short-time current rating of switching output [mA]: 1500; (20 ms / 0,5 Hz)
  • Switching frequency AC [Hz]: 25
  • Switching frequency DC [Hz]: 40
  • Overload protection: No
  • Sensing range adjustable: Yes
  • Factory setting sensing range [mm]: 15
  • Real sensing range Sr [mm]: 15 10 %
  • Operating distance [mm]: 0...12.1
  • Correction factor: Glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2
  • Hysteresis [% of Sr]: 1...15
  • Switch-point drift [% of Sr]: -15...15
  • Protection: IP 65
  • Increased immunity: yes; (Increased immunity to conducted radio frequency interference)
  • EMC: EN 60947-5-2
  • MTTF [years]: 468
  • Weight [g]: 136
  • Thread designation: M30 x 1.5
  • Display: Switching status 1 x LED, red
  • Required protection: miniature fuse to IEC60127-2 sheet 1; 2 A; fast acting
  • Accessories (supplied): Lock nuts: 2 screwdriver: 1
  • Remarks: Recommendation: check the unit for reliable function after a short circuit.
  • Pack quantity: 1 pcs.
  • Connection: Terminals: ...2.5 mm; Cable sheath: 7...13 mm; Cable gland: M20 X 1.5
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on KI0205 . Santa Clara Systems carries 2,078 items from Efector.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
