OGP300

Product Summary:

  • Electrical Design: Pnp
  • Output Function: Dark-On Mode
  • Material: Housing: Stainless Steel (1.4404 / 316L); Sealing: Epdm
  • Function Principle: Retro-Reflective Sensor
  • Operating Voltage [V]: 10...36 Dc
Let Us Find It

Current response time:

By 5AM PT on Monday
  • Description: Retro-reflective Sensor | OGP-DPKG/US100
  • Electrical Design: Pnp
  • Output Function: Dark-On Mode
  • Material: Housing: Stainless Steel (1.4404 / 316L); Sealing: Epdm
  • Function Principle: Retro-Reflective Sensor
  • Operating Voltage [V]: 10...36 Dc
  • Current Consumption [Ma]: 15
  • Protection Class: Ii
  • Reverse Polarity Protection: Yes
  • Type Of Light: Red Light
  • Wave Length [Nm]: 624
  • Max. Voltage Drop Switching Output Dc [V]: 2.5
  • Permanent Current Rating Of Switching Output Dc [Ma]: 150; (200 (...60 C))
  • Switching Frequency Dc [Hz]: 1000
  • Short-Circuit Protection: Yes
  • Type Of Short-Circuit Protection: Yes (Non-Latching)
  • Overload Protection: Yes
  • Range Referred To Prismatic Reflector [M]: 0.03...4; (Prismatic Reflector 80 E20005)
  • Range Adjustable: No
  • Max. Light Spot Diameter [Mm]: 160
  • Light Spot Dimensions Refer To: At Maximum Range
  • Polarization Filter Available: Yes
  • Ambient Temperature [C]: -25...80
  • Protection: Ip 67; Ip 68; Ip 69K
  • Emc: En 60947-5-2
  • Housing: Threaded Type
  • Dimensions [Mm]: M18 X 1 / L = 60
  • Thread Designation: M18 X 1
  • Lens Material: Pmma
  • Display: Switching Status 1 X Led, Yellow
  • Accessories (Supplied): Lock Nuts: 2 X
  • Connection: Connector: 1 X M12
  • Alternate Manufacturer Name: IFM
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on OGP300 . Santa Clara Systems carries 2,078 items from Efector.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
