• Efector PK6220 Pressure Sensor | Pk-400-SFN14-Hcpkg/US/ /W Product Image
  • Efector PK6220 Pressure Sensor | Pk-400-SFN14-Hcpkg/US/ /W Product Image
  • Efector PK6220 Pressure Sensor | Pk-400-SFN14-Hcpkg/US/ /W Product Image
  • Efector PK6220 Pressure Sensor | Pk-400-SFN14-Hcpkg/US/ /W Product Image
  • Efector PK6220 Barcode

PK6220

Product Summary:

  • Electrical Design: Pnp
  • Output Function: Complementary
  • Material: Pbt; Pc; Fkm; Stainless Steel (1.4404 / 316L)
  • Media: Liquids And Gases
  • Medium Temperature [C]: -25...80
Get a Quote

Current response time:

14 Minutes 18 Seconds
  • Description: Pressure Sensor | Pk-400-SFN14-Hcpkg/US/ /W
  • Electrical Design: Pnp
  • Output Function: Complementary
  • Material: Pbt; Pc; Fkm; Stainless Steel (1.4404 / 316L)
  • Media: Liquids And Gases
  • Medium Temperature [C]: -25...80
  • Pressure Rating: 600 Bar 8700 Psi
  • Min. Bursting Pressure: 1600 Bar 23200 Psi
  • Type Of Pressure: Relative Pressure
  • Operating Voltage [V]: 9.6...32 Dc
  • Current Consumption [Ma]: < 25
  • Min. Insulation Resistance [M?]: 100; (500 V Dc)
  • Protection Class: Iii
  • Reverse Polarity Protection: Yes
  • Number Of Inputs And Outputs: Number Of Digital Outputs: 2
  • Total Number Of Outputs: 2
  • Output Signal: Switching Signal
  • Number Of Digital Outputs: 2
  • Max. Voltage Drop Switching Output Dc [V]: 2
  • Permanent Current Rating Of Switching Output Dc [Ma]: 500
  • Switching Frequency Dc [Hz]: 100
  • Short-Circuit Protection: Yes
  • Type Of Short-Circuit Protection: Yes (Non-Latching)
  • Overload Protection: Yes
  • Measuring Range: 0...400 Bar 0...5800 Psi
  • Set Point Sp: 20...400 Bar 290...5800 Psi
  • Reset Point Rp: 12...392 Bar 175...5685 Psi
  • Switch Point Accuracy [% Of The Final Value]: < 2,5; (Setting Accuracy)
  • Repeatability [% Of The Final Value]: < 0,5; (With Temperature Fluctuations < 10 K)
  • Characteristics Deviation [% Of The Final Value]: < 1,5 (Bfsl) / < 2,5 (Ls); (Bfsl = Best Fit Straight Line; Ls = Limit Value Setting)
  • Temperature Drift Per 10 K: < 0.5
  • Adjustment Of The Switch Point: Setting Rings
  • Ambient Temperature [C]: -25...80
  • Storage Temperature [C]: -40...100
  • Protection: Ip 67
  • Emc: En 61000-4-2 Esd 4 Kv Cd / 8 Kv Ad En 61000-4-3 Hf Radiated 10 V/M En 61000-4-4 Burst 2 Kv En 61000-4-5 Surge 1 Kv Signal For Dc Units En 61000-4-6 Hf Conducted 10 V
  • Shock Resistance: Din Iec 68-2-27 50 G (11 Ms)
  • Vibration Resistance: Din Iec 68-2-6 20 G (10...2000 Hz)
  • Materials (Wetted Parts): Stainless Steel (1.4404 / 316L)
  • Min. Pressure Cycles: 50 Million
  • Process Connection: Threaded Connection 1/4 Npt External Thread Internal Threadm5
  • Display: Power Led, Green Switching Status Led, Yellow
  • With Scale: Yes
  • Connection: Connector: 1 X M12
  • Alternate Manufacturer Name: IFM
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on PK6220 . Santa Clara Systems carries 2,078 items from Efector.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
