SIES-8M-PS-24V-K-0-3-M8D

Festo - Proximity Sensor

Product Summary:

Size: Slot 8
Ambient temperature: -25 °C ... 70 °C
Switching output: PNP
Switching element function: N/O contact
DC operating voltage range: 10 V - 30 V

Current response time:

9 Minutes 33 Seconds

Description: Proximity Sensor
Size: Slot 8
Ambient temperature: -25 °C ... 70 °C
Switching output: PNP
Switching element function: N/O contact
DC operating voltage range: 10 V - 30 V
Design: For T-slot
Conforms to standard: EN 60947-5-2
Symbol: 00991701
Certification: RCM compliance mark c UL us - Listed (OL)
CE marking (see declaration of conformity): As per EU EMC directive As per EU RoHS directive
KC characters: KC EMC
Measured variable: Position
Measuring principle: Inductive
Rated operating distance: 1.5 mm
Reduction factors: Aluminum = 0.62 Stainless steel V2A = 0.95 Copper = 0.6 Brass = 0.72 Steel St 37 = 1.0
Repetition accuracy under constant conditions: <= 0.05 mm, approach from the side
On time: ≤1.0E-4 ms
Max. switching frequency: 4500 Hz
Max. output current: 150 mA
Max. switching capacity DC: 4.5 W
Voltage drop: ≤2 V
Inductive protective circuit: Installed
Minimum load current: 0 mA
Residual current: ≤0.01 mA
Short-circuit protection: Pulsed
Overload protection: Available
Residual ripple: 10 %
Idle current: ≤10 mA
Reverse polarity protection: For all electrical connections
Electrical connection 1, connection type: Cable with plug

Electrical connection 1, connection technology: M8x1 A-coded as per EN 61076-2-104
Electrical connection 1, number of pins/wires: 3
Electrical connection 1, type of mounting: Screw-type lock
Electrical connection for input 1, connection pattern: 00991155
Connection outlet orientation: Longitudinal
Material of pin contacts: Brass, gold-plated
Connector cable test conditions: Flexural strength: as per Festo standard Test conditions on request Energy chain > 5 million cycles, bending radius 75 mm
Cable length: 0.3 m
Cable characteristic: Standard/suitable for energy chains
Color cable sheath: Gray
Material of cable sheath: TPE-U(PU)
Insulating sheath material: PP
Type of mounting: Flush with T-slot Screwed tightly Can be inserted in slot from above
Tightening torque: 0.6 Nm
Mounting position: Any
Mounting type: Flush
Housing colour: Black
Housing material: Brass, nickel-plated PA PUR High-alloy stainless steel
Switching status indication: LED yellow
Ambient temperature with flexible cable installation: -5 °C ... 70 °C
Degree of protection: IP65 IP67
Insulation voltage: 50 V
Surge resistance: 0.8 kV
Corrosion resistance class (CRC): 2 - Moderate corrosion stress
LABS (PWIS) conformity: VDMA24364-B2-L
Cleanroom class: Class 4 according to ISO 14644-1
Contamination level: 3
Selection of additional sensor information: For T-slot
Electrical output: PNP
Selection of sensor version: Special design
