VMPA1-M1H-G-PI

Festo - Air Solenoid Valve

Current response time:

By 5AM PT on Monday

Emergency?

Description: Air Solenoid Valve
Ambient temperature: -5 C ... 50 C
Relative air humidity: Max. 90 % at 40 C
Lap: Overlap
Actuation type: Electrical
Valve size: 10 mm
Standard nominal flow rate: 320 l/min
Operating voltage: 24V DC
Operating pressure: "-0.9 bar ...
Design: Piston gate valve
Reset method: Mechanical spring
Degree of protection: as per IEC 60529 IP65
Certification: c UL us - Recognized (OL)
Type code: VMPA1
Sealing principle: Soft
Mounting position: Any
Manual override: Detenting Non-detenting
Type of control: Pilot-controlled
Flow direction: Reversible
Symbol: 991020
Signal status display: yes
Pilot pressure: 3 bar ... 8 bar
Suitability for vacuum: yes
Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4]

Corrosion resistance class (CRC): 1 - Low corrosion stress
Storage temperature: -20 C ... 40 C
Temperature of medium: -5 C ... 50 C
Max. tightening torque for valve mounting: 0.25 Nm
Product weight: 56 g
Type of mounting: With through-hole
Seals material: NBR
Housing material: Die-cast aluminum
Stroke: 25 mm
Piston diameter: 50 mm
Valve function: 5/3, closed
Structural design: Piston gate valve
Pilot pressure MPa: 0.3 MPa ... 0.8 MPa
Standard nominal flow rate with QS-6: 320 l/min
Switching time off: 35 ms
On switching time: 10 ms
Changeover time: 15 ms
Max. positive test pulse with 0 signal: 400 s
Max. negative test pulse on 1 signal: 200 s
Permissible voltage fluctuations: +/- 25 %
Information on operating and pilot media: Operation with oil lubrication possible (required for further use)
Vibration resistance: Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Shock resistance: Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
LABS (PWIS) conformity: VDMA24364-B1/B2-L

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on VMPA1-M1H-G-PI . Santa Clara Systems carries 5,553 items from Festo.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
