IC693MDL753

Product Summary:

  • Rated Voltage: 12 through 24 volts DC, positive logic
  • Outputs per Module: 32 (four groups of eight outputs each)
  • Isolation: 1500 volts between field side and logic side; 250 volts between groups
  • Inrush Current: 5.4 amps for 10 ms
  • On-state Voltage Drop: 0.3 volts DC
Get a Quote

Current response time:

By 5AM PT on Friday
  • Description: Output Module 12/24 VDC
  • Output Current: 0.5 amps per point with 4 amps maximum per group and 3 amps maximum per group common pin
  • Type if Device: 12/24 Volt DC, 0.5A Positive Logic Output, 32 Point, Series 90-30 Programmable Logic Controller
  • Rated Voltage: 12 through 24 volts DC, positive logic
  • Outputs per Module: 32 (four groups of eight outputs each)
  • Isolation: 1500 volts between field side and logic side; 250 volts between groups
  • Inrush Current: 5.4 amps for 10 ms
  • On-state Voltage Drop: 0.3 volts DC
  • Off-state Leakage Current: 0.1 mA maximum
  • On Response Time: 0.5 ms maximum
  • Off Response Time: 0.5 ms maximum
  • Internal Power Consumption: 260 mA (maximum) from 5 volt bus on backplane; (13 mA + 3 mA/point ON + 4.7 mA/LED)
  • Direct Method: This method uses cables that have a mating female connector on the module end and stripped and tinned wires on the other end. You can purchase a pair of pre-wired cables, catalog numbers IC693CBL327 and IC693CBL328 or, if required for your application, build your own cables. Refer to Building Cables for 24-Pin Connectors in the IC693CBL327/328 data sheet in Appendix C of this manual for more information.
  • Using a TBQC: The Terminal Block Quick Connect method uses a pair of cables with connectors on each end. These connect from the module connectors to connectors on DIN?rail mounted terminal blocks.The TBQC components are discussed in Appendix D.
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on IC693MDL753 . Santa Clara Systems carries 5,875 items from General Electric.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
