SH-809

Keyence - Proximity Sensor

Product Summary:

Weight: Approx. 55 g
Type: Heat-resistant*2 Shielded Cylindrical
Shape: ø9.4×18 Cylindrical
Detectable object: Ferrous metal (see Characteristics for nonferrous metals)
Standard target (iron, t=1 mm 0.04"): 15 x 15 mm 0.59" x 0.59"*3

Current response time:

By 5AM PT on Wednesday

Emergency?

Description: Proximity Sensor
Weight: Approx. 55 g
Footnotes: *1 The EG-547(W) cannot be used in combination with SH-422, 430, 440, 290, 809, 816 and 822. *2 Precautions when using heat-resistant sensor head? Use the sensor within the stable detecting range. The heat-resistant sensor head is not waterproof; do not use this sensor head in a location directly exposed to liquid or steam. *3 Above values obtained when the detecting distance is set at 50% of the maximum stable detecting distance.
Type: Heat-resistant*2 Shielded Cylindrical
Shape: ø9.4×18 Cylindrical
Detectable object: Ferrous metal (see Characteristics for nonferrous metals)
Standard target (iron, t=1 mm 0.04"): 15 x 15 mm 0.59" x 0.59"*3
Stable detecting range: 0.5 to 2 mm 0.02" to 0.08"

Repeatability: 0.002 mm 0.00008"*3
Hysteresis: 0.04 mm 0.002"*3
Temperature characteristics: 0.2%/°C*3
Environmental resistance - Enclosure rating: Heat-resistant
Environmental resistance - Operating temperature range: -10 to 200°C 14 to 392°F, No condensation
Environmental resistance - Operating ambient humidity: 35 to 85% RH (No condensation)
Environmental resistance - Vibration: 10 to 55 Hz, 1.5 mm 0.06" double amplitude in X, Y, and Z directions, 2 hours respectively

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on SH-809 . Santa Clara Systems carries 2,147 items from Keyence.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
