SR-1000

Keyence - Scanner

Current response time:

By 5AM PT on Monday

Emergency?

Description: Scanner
Weight: Approx 200 g
Footnotes: *1 The focal position can be adjusted automatically during installation.
Type: Standard type
Receiver - Sensor: CMOS Image Sensor
Receiver - Number of pixels: 1280 1024 pixels
Focus adjustment: Autofocus*1
Light emitter - Illumination light source: High intensity red LED
Light emitter - Pointer light source: High intensity green LED
Reading specifications - Supported symbol - 2D: QR, MicroQR, DataMatrix (ECC200), GS1 DataMatrix, PDF417, Micro PDF417, GS1 Composite (CC-A, CC-B, CC-C)
Reading specifications - Supported symbol - Barcode: CODE39, ITF, 2of5 (Industrial 2of5), COOP 2of5, NW-7 (Codabar), CODE128, GS1-128, GS1 DataBar, CODE93, JAN/EAN/UPC, Trioptic CODE39, CODE39 Full ASCII, Pharmacode
Reading specifications - Minimum resolution - 2D: 0.063 mm 0.002"
Reading specifications - Minimum resolution - Barcode: 0.082 mm 0.003"
Reading specifications - Reading distance: 110 to 1000 4.33" to 39.37"
Reading specifications - Field of view for reading: 122 97 mm 4.80" x 3.82" (Typical example at 400 mm 15.75")
I/O specifications - Control input - Number of Inputs: 2
I/O specifications - Control input - Input type: Bidirectional voltage input
I/O specifications - Control input - Maximum rating: 26.4 VDC
I/O specifications - Control input - Minimum ON voltage: 15 VDC
I/O specifications - Control input - Maximum OFF current: 0.2 mA or less
I/O specifications - Control output - Number of Outputs: 3

I/O specifications - Control output - Output type: Photo MOS relay output
I/O specifications - Control output - Maximum rating: 30 VDC
I/O specifications - Control output - Maximum load current: 1 output : 50 mA or less, Total of 3 outputs : 100 mA or less
I/O specifications - Control output - Leakage current when OFF: 0.1 mA or less
I/O specifications - Control output - Residual voltage when ON: 1 V or less
I/O specifications - Ethernet - Communication standard: IEEE 802.3 compliant, 10BASE-T/100BASE-TX
I/O specifications - Ethernet - Supported protocol: TCP/IP, SNTP, FTP, BOOTP, MC Protocol, Omron PLC link, KV STUDIO, EtherNet/IPTM, PROFINET
I/O specifications - Serial communication - Communication standard: RS-232C compliant
I/O specifications - Serial communication - Transmission speed: 9600, 19200, 38400, 57600, 115200 bps
I/O specifications - Serial communication - Supported protocol: No-protocol, MC Protocol, SYSWAY, KV STUDIO
I/O specifications - USB - Communication standard: USB 2.0 Full Speed compliant
Environmental resistance - Enclosure rating: IP65
Environmental resistance - Operating temperature range: 0 to +45C 32 to 113F
Environmental resistance - Ambient temperature for storage: -10 to +50C 14 to 122F
Environmental resistance - Operating ambient humidity: 35 to 85% RH (No condensation)
Environmental resistance - Storage ambient humidity: 35 to 85% RH (No condensation)
Environmental resistance - Operating ambient luminance: Sunlight : 10000 lux, Incandescent lamp : 6000 lux, Fluorescent lamp : 2000 lux
Environmental resistance - Operating environment: No dust or corrosive gas present
Environmental resistance - Vibration: 10 to 55 Hz Double amplitude 0.75 mm 0.030", 3 hours each in X, Y and Z directions
Rating - Power voltage: 24 VDC 10%
Rating - Current consumption.: Approx 700 mA

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on SR-1000 . Santa Clara Systems carries 2,098 items from Keyence.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
