• Modicon BMX DAI1604 discrete input module M340 - 16 inputs - 100..120 V AC Product Image
  • Modicon BMX DAI1604 discrete input module M340 - 16 inputs - 100..120 V AC Product Image
  • Modicon BMX DAI1604 discrete input module M340 - 16 inputs - 100..120 V AC Product Image
  • Modicon BMX DAI1604 discrete input module M340 - 16 inputs - 100..120 V AC Product Image
  • Modicon BMX DAI1604 Barcode

BMXDAI1604

Product Summary:

  • Range of product: Modicon X80
  • Product weight: 0.25 lb(US) (0.115 kg)
  • Electrical connection: 20-way connector
  • Input type: Capacitive
  • Protective treatment: TC
Get a Quote

Current response time:

By 5AM PT on Monday
  • Description: discrete input module M340 - 16 inputs - 100..120 V AC
  • Range of product: Modicon X80
  • Product weight: 0.25 lb(US) (0.115 kg)
  • Electrical connection: 20-way connector
  • Input type: Capacitive
  • Protective treatment: TC
  • Standards: UL 61010-2-201, EN/IEC 61131-2, CSA C22.2 No 61010-2-201, EN/IEC 61010-2-201
  • Relative humidity: 5...95 % without condensation
  • Operating altitude: 0...6561.68 ft. (0...2000 m), 2000...5000 m (with derating factor)
  • Protection type: 1 external fuse per group of channel 0.5 A fast blow
  • Network frequency: 50/60 Hz
  • IP degree of protection: IP20
  • Product or component type: Discrete input module
  • Network frequency limits: 47...63 Hz
  • Product certifications: RCM, CSA, CE, Merchant Navy, UL, EAC
  • Sensor power supply: 20...26 V
  • Discrete input number: 16
  • Voltage state 1 guaranteed: >= 74 V
  • Dielectric strength: 1500 V AC at 50/60 Hz 1 min
  • Discrete input type: Isolated
  • Current state 1 guaranteed: >= 2.5 mA
  • Vibration resistance: 3 gn
  • Voltage state 0 guaranteed: <= 20 V
  • Shock resistance: 30 gn
  • Discrete input voltage: 100...120 V AC
  • Current state 0 guaranteed: <= 1 mA
  • Ambient air temperature for storage: -40...185 F (-40...85 C)
  • Discrete input current: 5 mA
  • Input impedance: 13000 Ohm
  • Ambient air temperature for operation: 32...140 F (0...60 C)
  • Input compatibility: With 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2
  • Insulation resistance: > 10 MOhm 500 V DC
  • power dissipation in W: <= 3.8 W
  • AC activation filtering time: 10 ms
  • AC deactivation filtering time: 20 ms
  • Typical current consumption: 90 mA at 3.3 V DC
  • MTBF reliability: 1504958 H
  • Voltage detection threshold: < 40 V DC sensor fault, > 82 V DC sensor OK
  • status LED: 1 LED green module operating (RUN), 1 LED per channel green channel diagnostic, 1 LED red module I/O, 1 LED red module error (ERR)
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on BMXDAI1604 . Santa Clara Systems carries 1,951 items from Modicon.
  • Discrete Input Module M340 - 16 Inputs - 100..120 V Ac
