E2F-X5E1

Omron - Proximity Switch

Product Summary:

Type: Shielded
Sensing Method: Inductive Type
Sensing Distance: 5 mm-10% to +10%
Differential Distance: 10% Max. of sensing distance
Sensing Object: Ferrous metal (Sensitivity lowers with non-ferrous metals.)

Current response time:

By 5AM PT on Monday

Emergency?

Description: Proximity Switch
Type: Shielded
Sensing Method: Inductive Type
Sensing Distance: 5 mm-10% to +10%
Differential Distance: 10% Max. of sensing distance
Sensing Object: Ferrous metal (Sensitivity lowers with non-ferrous metals.)

Standard Sensing Object: Iron 18 x 18 x 1 mm
Power Supply Voltage: 12 to 24 VDC ripple(p-p) 10% Max.
Operating Voltage Range: 10 to 30 VDC
Current Consumption: 17 mA max.
Control Output (Output type): NPN voltage-current output

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on E2F-X5E1 . Santa Clara Systems carries 8,995 items from Omron.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
