VS-VE18-4N3240

Sick - Through-Beam Photoelectric Sensor | 6013686

Current response time:

By 5AM PT on Monday

Emergency?

Description: Through-Beam Photoelectric Sensor | 6013686
Connection Type: Male Connector M12, 4-Pin
Light Source: LED
Sensing Range: 0 m ... 14 m
Supply Voltage: 10 V DC ... 30 V DC
Switching Frequency: 250 Hz
Output Type: NPN, Open Collector
Response Time: 2 ms
Housing Design (Light Emission): Cylindrical, Straight
Housing Length: 78 mm
Thread Diameter (Housing): M18 x 1
Optical Axis: Axial

Sensing Range Max.: 0 m ... 20 m
Type of Light: Infrared Light
Light Spot Size (Distance): Ø 700 mm (14 m)
Angle of Dispersion: Approx. 2.8°
Adjustment: Potentiometer, 270° (Sensitivity)
Ripple: 10 %
Power Consumption: 30 mA
Switching Mode: Light/Dark Switching
Switching Mode Selector: Selectable Via L/D Control Cable
Output Current I: 100 mA
Ambient Operating Temperature: 25 °C ... +70 °C

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on VS-VE18-4N3240 . Santa Clara Systems carries 4,654 items from Sick.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
