WL27-3P3402S17

Sick - Photoelectric Sensor | 1051529

Current response time:

By 5AM PT on Friday

Emergency?

Description: Photoelectric Sensor | 1051529
Connection Type: Cable with M12 Male Connector, 4-Pin, 270 mm
Light Source: PinPoint LED
Sensing Range: 0 m ... 1.5 m
Output Function: Complementary
Supply Voltage: 10 V DC ... 30 V DC
Switching Frequency: 200 Hz
Output Type: PNP
Sensor/Detection Principle: Reflex Array
Dimensions (W x H x D): 24.6 mm x 80 mm x 54.2 mm

Sensing Range Max.: 0 m ... 1.5 m
Type of Light: Visible Red Light
Distance of the Sensor to Reflector: 0.5 m ... 1.5 m
Minimum Object Size: 5 mm, Position-Independent Detection Within the Light Array
Adjustment: Single Teach-In Button
Special Features: Detection Height 24 mm
Switching Mode: Light/Dark Switching
Ambient Operating Temperature: 30 C ... +60 C
Ambient Storage Temperature: 40 C ... +75 C

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on WL27-3P3402S17 . Santa Clara Systems carries 4,503 items from Sick.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
