WT9L-P430
In stock and ready to ship
Product Summary:
- Connection Type: Male Connector M12, 4-pin
- Light Source: Laser
- Weight: 20 g
- Output Function: Complementary
- Supply Voltage: 10 V DC ... 30 V DC
- Description: Photoelectric Sensor | 1023959
- Connection Type: Male Connector M12, 4-pin
- Light Source: Laser
- Weight: 20 g
- Output Function: Complementary
- Supply Voltage: 10 V DC ... 30 V DC
- Housing Material: Plastic, ABS
- Sensor/ Detection Principle: Photoelectric Proximity Sensor, Background Suppression
- Dimensions (W x H x D): 12 mm x 40 mm x 22 mm
- Housing Design (Light Emission): Rectangular
- Type of Light: Visible Red Light
- Light Spot Size (Distance): Ø 0.5 mm (60 mm)
- Sensing Range Max.: 30 mm ... 150 mm
- Laser Class: 2 (IEC 60825-1 / CDRH 1040.10)
- Adjustment: Potentiometer, 7 Turns
- Switching Output: PNP
- Switching Mode: Light/Dark Switching
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on WT9L-P430 . Santa Clara Systems carries 5,188 items from Sick.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
