GS2JU3N

Telemecanique - Disconnect Switch

Current response time:

By 5AM PT on Thursday

Emergency?

*Santa Clara Systems is not a Telemecanique Authorized Distributor.

Description: Disconnect Switch
IP degree of protection: IP20 conforming to IEC 60529 (with terminal cover)
Standards: CSA C22.2 No 4
Device short name: GS2JU
Width: 149.3 mm
Height: 186 mm
Depth: 122.2 mm
[Ui] rated insulation voltage: 750 V
[Uimp] rated impulse withstand voltage: 8 kV
Mechanical durability: 10000 cycles
Tightening torque: Power circuit: 4 N.m
Connections - terminals: Lugs-ring terminals
Range: TeSys
Mounting support: Plate
[Ith] conventional free air thermal current: 100 A (at 40 °C)
Product name: TeSys GS
Electrical durability: 6000 cycles
[Ie] rated operational current: 100 A
Poles description: 3P
Fuse type: UL

Fuse size: J
Product or component type: Switch-disconnector-fuse
Device application: Protection
Protected poles description: 3t
Contacts type and composition: 3 NO
Network type: AC
Network frequency: 50/60 Hz
Type of operating handle: External frontal
rated operational power in W: 51 kW at 400 V
Short-circuit withstand: 22 kA
Ambient air temperature for operation: -20…70 °C
Ambient air temperature for storage: -40…80 °C
Fire resistance: 960 °C body
Net weight: 2.761 kg
REACh Regulation: REACh Declaration
REACh free of SVHC: Yes
EU RoHS Directive: Compliant
Toxic heavy metal free: Yes
Mercury free: Yes
RoHS exemption information: Yes
