VW3A58101U

Telemecanique - AC Drive Keypad | Altivar

Product Summary:

Product weight: 24.25 lb(US) (11 kg)
Range of product: Altivar
IP degree of protection: IP00 (choke)IP10 (terminals)
Standards: VDE 0160 level 1IEC 60076 (with HD398)EN 50178
Width: 7.09 in (180 mm)

Current response time:

17 Minutes 46 Seconds

*Santa Clara Systems is not a Telemecanique Authorized Distributor.

Description: AC Drive Keypad | Altivar
Product weight: 24.25 lb(US) (11 kg)
Range of product: Altivar
IP degree of protection: IP00 (choke)IP10 (terminals)
Standards: VDE 0160 level 1IEC 60076 (with HD398)EN 50178
Width: 7.09 in (180 mm)
Height: 8.27 in (210 mm)
Depth: 6.5 in (165 mm)
Operating altitude: <= 3280.84 ft. (1000 m) without current derating<= 3280.84 ft. (1000 m) without derating
Vibration resistance: 1.5 mm peak to peak (f = 3...13 Hz) conforming to IEC 60068-2-61 gn (f = 13...200 Hz) conforming to IEC 60068-2-6
Shock resistance: 15 gn 11 ms conforming to IEC 60068-2-27
Electrical connection: Terminal 35 mm² / AWG 0, 22.12...26.55 lbf.in (2.5...3 N.m)
Relative humidity: 0...95 %
Product destination: Drive controller ATV58TRX
Package weight(Lbs): 0.81000000000000005
Supply frequency: 50...60 Hz
Product or component type: Line/motor choke

Max current: 1.65 x nominal current 60 s
Product compatibility: LXM32MD85N4 - line choke - 1 per driveLXM32MC10N4 - line choke - 1 per driveATV61CD15N4 - motor choke - 1 per driveATV61HD11M3X - line choke - 1 per driveATV61HD15N4 - motor choke - 1 per driveATV61HD18N4 - line choke - 1 per driveATV61HD22N4 - line choke - 1 per driveATV61HD30Y - line choke - 1 per driveATV61HD37Y - line choke - 1 per driveATV61HD45Y - line choke - 1 per driveATV61HU75M3 - line choke - 1 per driveATV61KD15N4 - motor choke - 1 per driveATV61WD18N4 - line choke - 1 per driveATV61WD18N4C - line choke - 1 per driveATV61WD22N4 - line choke - 1 per driveATV61WD22N4C - line choke - 1 per driveATV71HD11M3X - line choke - 1 per driveATV71HD18N4 - line choke - 1 per driveATV71HD22N4 - line choke - 1 per driveATV71HD30Y - line choke - 1 per driveATV71HD37Y - line choke - 1 per driveATV71HD45Y - line choke - 1 per driveATV71HU75M3 - line choke - 1 per driveATV71WD18N4 - line choke - 1 per driveATV71WD22N4 - line choke - 1 per driveATV312HD11M3 - line choke - 1 per driveATV312HD15M3 - line choke - 1 per driveATV32HD15N4 - motor choke - 1 per driveVariable speed drive ATV340 motor : 15 kW 380...480 V - line choke - 1 per driveVariable speed drive ATV340 motor : 18 kW 380...480 V - line choke - 1 per driveVariable speed drive ATV340 motor : 22 kW 380...480 V - line choke - 1 per driveVariable speed drive ATV320 motor : 15 kW 380...500 V - three phase - motor choke - 1 per driveVariable speed drive ATV320 motor : 11 kW 200...240 V - three phase - line choke - 1 per driveVariable speed drive ATV320 motor : 15 kW 200...240 V - three phase - line choke - 1 per driveVariable speed drive ATV630 motor : 30 kW 500...690 V - three phase - line choke - 1 per driveVariable speed drive ATV630 motor : 37 kW 500...690 V - three phase - line choke - 1 per driveVariable speed drive ATV630 motor : 45 kW 500...690 V - three phase - line choke - 1 per driveVariable speed drive ATV930 motor : 30 kW 500...690 V - three phase - line choke - 1 per driveVariable speed drive ATV930 motor : 37 kW 500...690 V - three phase - line choke - 1 per driveVariable speed drive ATV930 motor : 45 kW 500...690 V - three phase - line choke - 1 per driveVariable speed drive ATV630 motor : 600 V - three phase - line choke - 40 hp - 1 per driveVariable speed drive ATV630 motor : 600 V - three phase - line choke - 50 hp - 1 per driveVariable speed drive ATV630 motor : 600 V - three phase - line choke - 60 hp - 1 per driveVariable speed drive ATV930 motor : 600 V - three phase - line choke - 40 hp - 1 per driveVariable speed drive ATV930 motor : 600 V - three phase - line choke - 50 hp - 1 per driveVariable speed drive ATV930 motor : 600 V - three phase - line choke - 60 hp - 1 per drive
Voltage drop at rated load: 3...5 %
Environmental characteristic: 3B1 conforming to IEC 721-3-33C2 conforming to IEC 721-3-33S1 conforming to IEC 721-3-3
Phase: Three phase
Electrical insulation class: Class F
Pollution degree: 2 conforming to EN 50178
Range compatibility: Altivar 71Altivar 312Altivar 32Lexium 62Altivar Process ATV600Lexium 32Altivar Machine ATV320Altivar Machine ATV340Altivar 61Altivar Process ATV900
Clearance distance: 0.22 in (5.5 mm) conforming to IEC 60664
Device application: Reduction of overvoltages at motor terminalsReduction of current harmonics
Leakage distance: 0.45 in (11.5 mm) conforming to IEC 60664
Value of inductance: 0.5 mH
Line Rated Current: 60 A
Ambient air temperature for operation: > 113...< 131 °F (> 45...< 55 °C) with current derating of 2 % per °C32...113 °F (0...45 °C) without current derating
Thermal losses: 94 W
Ambient air temperature for storage: -13...158 °F (-25...70 °C)

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on VW3A58101U . Santa Clara Systems carries 10,643 items from Telemecanique.
