• VAT 10836-PE44 UHV Gate Valve Product Image
  • VAT 10836-PE44 UHV Gate Valve Product Image
  • Vat 10836-PE44 Barcode

10836-PE44

Product Summary:

  • Body Material: Stainless steel
  • Solenoid: Yes
  • Position Indicator: Yes
  • Inside Diameter (ID) in mm (inches): 63 (2 1/2")
  • Flange: ISO-F (compatible with ISO 1609 Fig.1)
Get a Quote

Current response time:

By 5AM PT on Monday
  • Description: UHV Gate Valve
  • Actuator: Pneumatic Actuator with Position Indicator with Solenoid Valve Double Acting
  • Body Material: Stainless steel
  • Solenoid: Yes
  • Position Indicator: Yes
  • Inside Diameter (ID) in mm (inches): 63 (2 1/2")
  • Flange: ISO-F (compatible with ISO 1609 Fig.1)
  • Pressure Min: 1?10-10 mbar
  • Pressure Max: 1.6 bar (abs)
  • Molecular flow conductance ls-1: 600.0
  • Max. differential pressure (closed position in bar): 1.6
  • Max. pressure on seat side during opening in bar: 0.03
  • Valve body temperature max. in C: 250.0
  • Actuator temperature max. in C: 200.0
  • Position indicator temperature max. in C: 80.0
  • Weight in kg/lbs: 9 / 19.84
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on 10836-PE44 . Santa Clara Systems carries 5 items from VAT.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
