• Festo SMEO-1-LED-24-B Proximity Sensor Product Image
  • Festo SMEO-1-LED-24-B Proximity Sensor Product Image
  • Festo SMEO-1-LED-24-B Proximity Sensor Product Image
  • Festo SMEO-1-LED-24-B Proximity Sensor Product Image
  • Festo SMEO-1-LED-24-B Barcode

SMEO-1-LED-24-B

Product Summary:

  • Ambient temperature: -20 C ...70 C
  • Electrical connection: 3-wire Cable
  • Valve function: 5/3, exhausted
  • Lap: Overlap
  • Type code: SMEO
Get a Quote

Current response time:

By 5AM PT on Monday
  • Description: Proximity Sensor
  • Ambient temperature: -20 C ...70 C
  • Electrical connection: 3-wire Cable
  • Valve function: 5/3, exhausted
  • Lap: Overlap
  • Type code: SMEO
  • Design: Block design
  • Symbol: 991145
  • Certification: RCM compliance mark
  • CE marking (see declaration of conformity): As per EU EMC directive
  • Measuring principle: Magnetic reed
  • Switching output: Contact-based, bipolar
  • Switching element function: N/O contact
  • Reproducibility of switching value: +/- 0.1 mm
  • On time: 0.5 ms
  • Max. output current: 1000 mA
  • Min. switching capacity AC: 27 VA
  • Max. switching capacity DC: 27 W
  • Short-circuit protection: no
  • Overload protection: Not available
  • Operating voltage range AC: 12 V ...27 V
  • DC operating voltage range: 12 V ...27 V
  • Reverse polarity protection: no
  • Connection outlet orientation: Longitudinal
  • Cable length: 2.5 m
  • Material of cable sheath: TPE-U(PUR)
  • Type of mounting: With accessories
  • Mounting position: Any
  • Product weight: 85 g
  • Housing material: Die-cast zinc
  • Switching status indication: LED yellow
  • Ambient temperature with flexible cable installation: -5 C ...70 C
  • Degree of protection: IP67
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on SMEO-1-LED-24-B . Santa Clara Systems carries 1,027 items from Festo.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
