VN-07-M-I3-PQ2-VQ2-A

Festo - Vacuum Generator

Current response time:

By 5AM PT on Monday

Emergency?

Description: Vacuum Generator
Ambient temperature: 0 °C ... 60 °C
Nominal width of Laval nozzle: 0.7 mm
Width dimension: 14.5 mm
Mounting position: Any
Ejector characteristics: Inline - High negative pressure
Integrated function: Ejector pulse valve, pneumatic
Structural design: Straight design
Symbol: 00991484
Operating pressure for max. suction rate: 2 bar
Operating pressure: 1 bar ... 8 bar
Operating pressure for max. vacuum: 4.3 bar
Max. vacuum: 93 %
Nominal operating pressure: 6 bar
Max. suction rate with respect to atmosphere: 16.6 l/min
Air supply time at nominal operating pressure: 1.69 s
Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4]

Information on operating and pilot media: Operation with oil lubrication not possible
Corrosion resistance class (CRC): 1 - Low corrosion stress
LABS (PWIS) conformity: VDMA24364-B1/B2-L
Temperature of medium: 0 °C ... 60 °C
Cleaning advice: Soap suds
Noise level at nominal operating pressure: 75 dB(A)
Product weight: 41 g
Type of mounting: Line installation
Pneumatic connection 1: QS-6
Vacuum connection: QS-6
Material of connecting thread: Wrought aluminum alloy, anodized
Seals material: NBR
Female nozzle material: POM
Housing material: PA-reinforced POM-reinforced
Material of screws: Steel
Material of jet nozzle: Wrought aluminum alloy
Material of pneumatic fitting: Brass Nickel-plated
