EX-202

Product Summary:

  • Type: Controller
  • Shape: M10 Threaded
  • Measuring range: 0 to 2 mm 0.08"
  • Analog input - Output voltage: 0 to 5 V (output impedance 100)
  • Analog output - Output current: 4 to 20 mA (applicable load: 0 to 350)
Get a Quote

Current response time:

By 5AM PT on Monday
  • Description: Sensor Head Controller
  • Functions: Auto-zero function/Response frequency selecting function
  • Temperture charateristics: 0.04% of F.S./*C
  • Rating - Power supply voltage: 12 to 24 V DC +10%
  • Rating - Current consumption: 240 mA max.
  • Enviromental resistance - Enclosure rating: -
  • Enviromental resistance - Operating temperature range: 0 to 50*C 32 to 122*F
  • Enviromental resistance - Operating ambient humidity: 35 to 85% RH (No condensation)
  • Enviromental resistance - Vibration: 10 to 55 hz, double amplitude: 1.5 mm 0.06", 2 hours in each of X, Y, and Z directions
  • Weight: Approx. 285 g
  • Type: Controller
  • Shape: M10 Threaded
  • Measuring range: 0 to 2 mm 0.08"
  • Analog input - Output voltage: 0 to 5 V (output impedance 100)
  • Analog output - Output current: 4 to 20 mA (applicable load: 0 to 350)
  • Analog output - Resolution: 0.04% of F.S. (Response frequency: LOW)
  • Analog output - Linearity: +1% of F.S.
  • Analog output - Response frequency - HIGH: 15 kHz(-3 dB)
  • Analog output - Response frequency - LOW: 1.3 kHz (-3 dB)
  • Disconnection alarm output (N.C.): NPN: 100 mA (40 V) max., Residual voltage: 1 V max. (N.C.)
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on EX-202 . Santa Clara Systems carries 1,475 items from Keyence.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
