• Keyence FT-H30 Sensor Product Image
  • Keyence FT-H30 Sensor Product Image
  • Keyence FT-H30 Sensor Product Image
  • Keyence FT-H30 Sensor Product Image
  • Keyence FT-H30 Barcode

FT-H30

Product Summary:

  • Type: Mid to low temperature Long-range
  • Rated temperature range: 0 to 500C 32 to 932F*1
  • Displayable temperature range: -50 to +520C -58 to +968F
  • Detecting distance: Unlimited *2
  • Sight: 2-point visible laser beam*3
Get a Quote
           or
  • Description: Sensor
  • Environmental resistance - Operating temperature range: -10 to 55C 14 to 131F, No freezing
  • Environmental resistance - Operating ambient humidity: 35 to 85% RH (No condensation)
  • Environmental resistance - Vibration: 10 to 55 Hz, double amplitude: 1.5 mm 0.06", 2 hours in each of X, Y, and Z axis directions
  • Environmental resistance - Shock resistance: 500 m/s2, 10 times in each direction of each axis (X, Y, Z), 60 times in total
  • Material - Main unit: Case: Reinforced glass plastic, Infrared collector lens: Germanium, Laser transmitter: Polyarylate Lens tube*4: Aluminum, Cable: Vinyl chloride, Mounting bracket: SUS304, Mounting screw: Stainless steel
  • Material - Mounting bracket: SUS304
  • Accessories: Mounting bracket
  • Weight: Approx 120 g
  • Footnotes: *1 Repeatability is guaranteed within the rated temperature range. *2 Place at a distance so that object appears 1.5 times larger than the view diameter. *3 Visible semiconductor laser beam wavelength 655 nm, Class 1 Laser Product ?IEC60825-1, FDA (CDRH) Part1040.10?. The laser classification for FDA (CDRH) is implemented based on IEC 60825-1 in accordance with the requirements of Laser Notice No.50. *4 No lens tube on models FT-H10, FT-H20, and FT-H30.
  • Type: Mid to low temperature Long-range
  • Rated temperature range: 0 to 500C 32 to 932F*1
  • Displayable temperature range: -50 to +520C -58 to +968F
  • Detecting distance: Unlimited *2
  • Measuring distance / View diameter (example): 200/15 mm 7.87"/0.59" 400/18 mm 15.75"/0.71" 600/33 mm 23.62"/1.30"
  • Sight: 2-point visible laser beam*3
  • Detecting element: Thermopile
  • Detecting wavelength: 8 to 14 ?m 0.31 to 0.55 Mil
  • Repeatability: 0.5C 0.9F
  • Emissivity (?) correction: 0.10 to 1.99 (0.01 step)
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on FT-H30 . Santa Clara Systems carries 1,357 items from Keyence.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
