KFD2-SR2-EX1.W.LB

Pepperl+Fuchs - Switch Amplifier

Product Summary:

Switching frequency: < 10 Hz
Degree of protection: IP20
Mounting: on 35 mm DIN mounting rail acc. to EN 60715:2001
Rated voltage: 20 ... 30 V DC
Open circuit voltage/short-circuit current: approx. 8 V DC / approx. 8 mA

Current response time:

16 Minutes 30 Seconds

Description: Switch Amplifier
Switching frequency: < 10 Hz
Degree of protection: IP20
Mounting: on 35 mm DIN mounting rail acc. to EN 60715:2001
Rated voltage: 20 ... 30 V DC

Open circuit voltage/short-circuit current: approx. 8 V DC / approx. 8 mA
Switching point/switching hysteresis: 1.2 ... 2.1 mA / approx. 0.2 mA
Pulse/Pause ratio: min. 20 ms / min. 20 ms
Minimum switch current: 2 mA / 24 V DC
Control elements: DIP-switch
