ZLM1-C1111A10

Sick - Photoelectric Sensor Zone Control | 7027764

Product Summary:

Connection Type: Cable with Receptacle, M12, 4-pin, 0.5 m
Supply Voltage: 21.6 V DC
Switching Frequency: 200 Hz
Actuator: Pneumatic, Valve on Board
Logical Principle of Operation: Single Accumulation

Current response time:

7 Minutes 40 Seconds

Description: Photoelectric Sensor Zone Control | 7027764
Connection Type: Cable with Receptacle, M12, 4-pin, 0.5 m
Supply Voltage: 21.6 V DC
Switching Frequency: 200 Hz
Actuator: Pneumatic, Valve on Board
Logical Principle of Operation: Single Accumulation
Type of Release: Single Release, Block (Slug) Release

Dimensions (W x H x D): 30 mm x 110 mm x 70 mm
Switching Output: PNP
Connection Type for Daisy Chain: Cable with M12 Male Connector, 4-pin 1.2 m
Coil Ratings: 24 V DC 1 W
Connection Type Solenoid Valve: Compressed Air 3/8 " Diameter, Control Line 1/4 " Diameter
Mounting System Type: Side-Frame-Mount
Design Solenoid Valve: 3/2-Way Valve
