- Description: M35/16 Screw Clamp Terminal Blocks - Feed-through - Beige
- Product ID: 1SNA195124R0000
- Extended Product Type: 1SNA195124R0000
- Product Net Weight: 50 g
- Product Net Width: 16 mm
- Product Net Height: 49 mm
- Product Net Depth: 46.5 mm
- Degree of Protection: acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20
- Ambient Air Temperature: Operation -55 ... +110 C Storage -55 ... +110 C
- Rated Impulse Withstand Voltage (U<sub>imp</sub>): 8000 V
- Rated Current (I<sub>n</sub>): Main Circuit 125 A
- Function: Feed-through
- Color: Beige
- Mounting on DIN Rail: G32 (32 x 15 mm Mounting Rail) acc. to IEC 60715 TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
- Tightening Torque: acc. IEC 60947-1 2.8 N·m Manufacturer 3 N·m
- Connecting Capacity Main Circuit: Screw Clamp / Flexible 1x 1 ... 35 mm Screw Clamp / Rigid 1x 1 ... 50 mm Screw Clamp / With Insulated Ferrrule 1x 35 mm
- Maximum Operating Voltage UL/CSA: Main Circuit 600 V
- Rated Voltage (U<sub>r</sub>): 1000 V
- Connecting Capacity UL/CSA: Screw Clamp / Rigid 10 ... 0 AWG Stranded 0 AWG
- Spacing: 16 mm
- Dielectric Test Voltage: 3500 V
- Wire Stripping Length: 17.0 mm
- Insulation Material: Polyamide
- Connecting Capacity Main Circuit UL/CSA: Screw Clamp / Rigid 1x 10 ... 0 AWG
- Connection Type: Screw clamp
- Rated Cross-Section: 35 mm
- Number of Levels: 1
- Gauge Type: B9
- EAN: 3472591951240
- Minimum Order Quantity: 20 piece
- Customs Tariff Number: 85369010
- Rated Short-time Withstand Current (I<sub>cw</sub>): for 1 s 4200 A
- Pollution Degree: 3
- Recommended Screw Driver: 6.5 ... 7 mm
- Flammability According to UL94: V0
- RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
- Instructions and Manuals: 1SNC160019C0202
- CSA Certificate: 1SND161051A0202
- cUL Certificate: 1SND161001A0208
- Data Sheet, Technical Information: 1SNC160019C0202
- Declaration of Conformity - CE: 1SND225014U1000
- EAC Certificate: 1SND161009A1100
- RoHS Information: 1SND230023F0208
- ETIM 4: EC000897 - Feed-through terminal block
- ETIM 5: EC000897 - Feed-through terminal block
- ETIM 6: EC000897 - Feed-through terminal block
- Object Classification Code: X
- Package Level 1 Width: 81 mm
- Package Level 1 Length: 200 mm
- Package Level 1 Height: 53 mm
- Package Level 1 Gross Weight: 1 kg
- Package Level 1 EAN: 3472591951240
- Package Level 2 Units: 300 piece
- Package Level 2 Width: 300 mm
- Package Level 2 Length: 500 mm
- Package Level 2 Height: 150 mm
- Package Level 2 Gross Weight: 14.750 kg
- Package Level 3 Units: 14400 piece
- Product Packing Type: Box
- Package Level 1 Units: 20 piece
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on M35-16-1SNA195124R0000 . Santa Clara Systems carries 36,687 items from ABB.
- - Use Of Jumper Bars Requires The User To Cut Out The Partition.
- - Closed Terminal Block: No End Section Needed
- Optimized Rigidity
- - Flexibility: Snap Onto Symmetrical And Asymmetrical Rails
