- Description: Analog I/O Module | Series 90-30
- Type of Device: Input / Output Analog, Current / Voltage
- Product Description: Outputs can be configured to either Hold Last State or to reset to the low end of their range if system power is interrupted. Outputs can also be configured to operate in ramp mode on command from the application program. In ramp mode, the output channel transitions to a new value over a period of time, rather than taking the new value immediately. High and low alarm limits can be set for all input channels and an open-wire fault (current output modes) can be reported to the CPU for each output channel. ALG442 modules in RX3i racks support firmware upgrades in the field.
- External Supply Voltage Range: 20 to 30 VDC (24 VDC typical)
- Voltage Ripple: 10%
- Power Consumption: 95 mA from internal +5 VDC Supply, 150 mA from external +24 VDC supply
- Update Rate: Update Rate: 3 ms
- Isolation, Field to Backplane (optical) and to Frame Ground: 250 VAC continuous; 1500 VAC for 1 minute
- Analog Outputs: Two, Single?Ended
- Output Ranges: 0 to 20 mA, 4 to 20 mA
- Output Load Capacitance: 2000 pF (maximum)
- Output Load Inductance: 1 H (maximum)
- Number of Input Channels: 4 differential
- Input Ranges: 0 to 20 mA / 4 to 20 mA / 4 to 20 mA Enhanced
- Resolution 0 to +10V: 2.5 mV (1 LSB = 2.5 mV)
- Resolution -10 to +10V: 5 mV (1 LSB = 5 mV)
- Input Filter Response: 29 Hz
- Current Consumption From Internal +5V Supply: 95 mA
- Current Consumption From External User Supply: 129 mA
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on IC693ALG442 . Santa Clara Systems carries 6,143 items from General Electric.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
