• General Electric IC693 MDL 655 Input Module | Series 90-30 Product Image
  • General Electric IC693 MDL 655 Input Module | Series 90-30 Product Image
  • General Electric IC693 MDL 655 Input Module | Series 90-30 Product Image
  • General Electric IC693 MDL 655 Input Module | Series 90-30 Product Image
  • General Electric IC693 MDL 655 Barcode

IC693MDL655

Product Summary:

  • Type of Device: 24 VDC Positive/Negative Logic, 32 Point Input
  • Rated Voltage: 24 volts DC, Positive or Negative Logic
  • Input Voltage Range: 0 to 30 volts DC
  • Inputs per Module: 32 (four groups of eight inputs each)
  • Isolation: 1500 volts between field side and logic side 250 volts between groups
Get a Quote

Current response time:

15 Minutes 50 Seconds
  • Description: Input Module | Series 90-30
  • Type of Device: 24 VDC Positive/Negative Logic, 32 Point Input
  • Product Description: GE Fanuc Positive/negative logic discrete input module for 90 - 30 series PLC offers 32 discrete input points that are arranged in four isolated groups of eight. It has LED indicators at the top to offer ON/OFF status of each point. Module uses 32 bits of discrete input data. Module can be conveniently installed in any I/O slot of a 5 or 10-slot baseplate in a 90-30 series PLC system. Module connectors are connected to the field devices through a cable having a mating female connector on one end and stripped/tinned wires on the other end. It has a voltage rating of 0 - 30 VDC, current rating of 7 milli-Amps and a power rating of 195 milli-Amps at 5 VDC. Module has a maximum ON/OFF response time of 2 milli-seconds. Input/output module provides the interface between the PLC and external input devices such as proximity sensors, push buttons, switches and BCD thumbwheels. It supports different voltage ranges, types, current capacity, isolation and response time to meet your application.
  • Rated Voltage: 24 volts DC, Positive or Negative Logic
  • Input Voltage Range: 0 to 30 volts DC
  • Inputs per Module: 32 (four groups of eight inputs each)
  • Isolation: 1500 volts between field side and logic side 250 volts between groups
  • Input Current: 7.0 mA
  • On-state Voltage: 11.5 to 30 volts DC
  • Off-state Voltage: 0 to 5 volts DC
  • Internal Power Consumption: 195 mA (maximum) from +5V bus on backplane; (29 mA +0.5 mA/point ON +4.7 mA/LED ON)
  • Product Details: Input modules provide the interface between the PLC and external input devices such as proximity sensors, push buttons, switches and BCD thumbwheels. Output modules provide the interface between the PLC and external output devices such as contactors, interposing relays, BCD displays and indicator lamps.
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on IC693MDL655 . Santa Clara Systems carries 5,875 items from General Electric.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
