• Keyence GV-H1000 Barcode

GV-H1000

Product Summary:

  • Type: Ultra long-range
  • Laser class - FDA (CDRH) Part 1040.10: class 2 (560 ?W)
  • Laser class - IEC 60825-1: Class 2 (560 ?W)
  • Laser class - JIS C6802: class 2 (560 ?W)
  • Possible display range: 810 to -175
Let Us Find It
           or
  • Description: Laser Sensor
  • Environmental resistance - Enclosure rating: IP67
  • Environmental resistance - Operating temperature range: -10 to +50C 14 to 122F, No freezing
  • Environmental resistance - Operating ambient humidity: 35 to 85% RH (No condensation)
  • Environmental resistance - Operating ambient luminance - Incandescent lamp: 5000?x
  • Environmental resistance - Operating ambient luminance - Sunlight: 10000?x*2
  • Environmental resistance - Vibration: 10 to 55 Hz, 1.5 mm 0.06", double amplitude in the X, Y, and Z directions, 2 hours respectively
  • Material: Housing material: PBT, Display: Polyarylate, Metal: SUS304, Lens cover: Glass, Cable: PVC
  • Weight: Approx.210 g*3
  • Footnotes: *1 General guideline for amplifier display values relative to detection distance (when distance display mode is set to normal). *2 Incandescent lamp: 5000 lux, Sunlight: 3000 lux for GV-H1000 (When the response time is set to 10 ms or faster) *3 Including 2 m 6.6' connector cable (3 m 9.8' cable for GV-H1000)
  • Type: Ultra long-range
  • Light source: Visible semiconductor laser, Wavelength: 655 nm
  • Laser class - FDA (CDRH) Part 1040.10: class 2 (560 ?W)
  • Laser class - IEC 60825-1: Class 2 (560 ?W)
  • Laser class - JIS C6802: class 2 (560 ?W)
  • Detection distance (Amplifier display ): 200 to 1000 mm 7.87" to 39.37" (800 to 0)*1)
  • Possible display range: 810 to -175
  • Standard detection deviation: 20 mm 0.79" (Detection distance 200 to 800 mm 7.87" to 31.5") 30 mm 1.18" (Detection distance 800 to 1000 mm 31.5" to 39.37")
  • Spot diameter: Approx. 1.8 mm 0.07" (Detection distance 1000 mm 39.37")
  • Operation status indicators: Control output: Red LED/Laser radiation emission indicator: Green LED/1 spot indicator: Green LED
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on GV-H1000 . Santa Clara Systems carries 1,239 items from Keyence.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
