BMXDDO3202K

Product Summary:

  • Range of product: Modicon X80
  • Product weight: 0.24 lb(US) (0.11 kg)
  • Electrical connection: 40-way connector
  • Protective treatment: TC
  • Relative humidity: 5...95 % without condensation
Get a Quote

Current response time:

By 5AM PT on Friday
  • Description: discrete output module M340 - 32 outputs - solid state - 24 V DC positive
  • Range of product: Modicon X80
  • Product weight: 0.24 lb(US) (0.11 kg)
  • Electrical connection: 40-way connector
  • Protective treatment: TC
  • Standards: UL 61010-2-201, CSA C22.2 No 61010-2-201, EN/IEC 61131-2, EN/IEC 61010-2-201
  • Relative humidity: 5...95 % without condensation
  • Protection type: External short-circuit protection, Overload protection, Overvoltage protection, Reverse polarity protection
  • Operating altitude: 0...6561.68 ft. (0...2000 m), 2000...5000 m (with derating factor)
  • Switching frequency: 0.5/LI Hz
  • Current per channel: <= 0.125 A
  • IP degree of protection: IP20
  • Product or component type: Discrete output module
  • Current per module: <= 3.2 A
  • Product certifications: UL, CE, Merchant Navy, RCM, EAC, CSA
  • Leakage current: <= 0.1 mA at state 0
  • Discrete output number: 32 conforming to EN/IEC 61131-2
  • [Ures] residual voltage: <= 1.5 V at state 1
  • Dielectric strength: 1500 V AC at 50/60 Hz 1 minute, output/ground, 1500 V AC at 50/60 Hz 1 minute, output/internal logic, 500 V DC 1 minute, between group of channels
  • Discrete output type: Solid state
  • Insulation resistance: > 10 MOhm 500 V DC
  • Vibration resistance: 3 gn
  • Discrete output logic: Positive
  • power dissipation in W: <= 3.6 W
  • Shock resistance: 30 gn
  • Discrete output voltage: 24 V 19...30 V DC
  • Response time on output: 1.2 ms
  • Ambient air temperature for storage: -40...185 F (-40...85 C)
  • Discrete output current: 0.1 A
  • Paralleling of outputs: Yes : 3 maximum
  • Ambient air temperature for operation: 32...140 F (0...60 C)
  • Output compatibility: Not IEC 61131-2 DC input, IEC 61131-2 type 3 DC input
  • Typical current consumption: 150 mA at 3.3 V DC
  • MTBF reliability: 360412 H
  • Output overload protection: With current limiter, With electronic circuit breaker 0.125 A < Id < 0.185 A
  • Output overvoltage protection: With transil diode
  • Output short-circuit protection: With 2 A external fuse
  • Reverse polarity protection: Reverse mounted diode
  • Voltage detection threshold: < 14 V DC preactuator fault, > 18 V DC preactuator at state 0
  • Tungsten load: <= 1.2 W
  • Overload time: <= 15 ms
  • Load impedance ohmic: <= 220 Ohm
  • status LED: 1 LED green module operating (RUN), 1 LED per channel green channel diagnostic, 1 LED red module I/O, 1 LED red module error (ERR)
