EV-112M

Product Summary:

  • Type: Shielded
  • Shape: M12
  • Detecting distance: 2.5 mm 0.10" 10%
  • Standard target (iron, t=1 mm 0.04"): 12 x 12 mm 0.47" x 0.47"
  • Hysteresis: 10% max. of detecting distance
Get a Quote

Current response time:

16 Minutes 34 Seconds
  • Description: Proximity Switch
  • Rating - Power voltage: 12 to 24 VDC, Ripple (p-p) 20% max.
  • Rating - Current consumption (leakage current): Current consumption (leakage current): 1.0 mA max., Residual voltage: 3.6 V max. (with 2-m 6.6' cable)
  • Rating - Residual voltage: Residual voltage: 3.6 V max. (with 2-m 6.6' cable)
  • Environmental resistance - Enclosure rating: IP67
  • Environmental resistance - Operating temperature range: -25 to +80C -13 to 176F, No freezing
  • Environmental resistance - Operating ambient humidity: 35 to 95%, No condensation
  • Environmental resistance - Vibration: 10 to 55 Hz, 1.5 mm 0.06" double amplitude in X, Y, and Z directions, 2 hours
  • Environmental resistance - Shock resistance: 500 m/s2 1640.4' in X, Y, and Z directions, 3 times respectively
  • Case material: Nickel-plated brass
  • Accessories: Nut 2, toothed washer 1, instruction manual
  • Weight: Approx. 110 g
  • Type: Shielded
  • Shape: M12
  • Detecting distance: 2.5 mm 0.10" 10%
  • Detectable object: Ferrous metals (see Characteristics for nonferrous metals)
  • Standard target (iron, t=1 mm 0.04"): 12 x 12 mm 0.47" x 0.47"
  • Hysteresis: 10% max. of detecting distance
  • Response frequency: 600 Hz
  • Operation mode: N.O.
  • Temperature characteristics: 10% max. of detecting distance at 23C 73.4F, within -25 to +70C -13 to +158F
  • Control output (switching capacity): 5 to 200 mA
  • Protection circuit: Reversed polarity, short-circuit, surge voltage
  • Cable length: 2 m 6.6'
